JBETT Explosion-Proof Solvent Recycler, Professional Waste Thinner Recovery Machine for Spraying Coating Industry.
Product Introduction
JBETT Explosion-Proof Solvent Recycler | Exclusive for Spraying Industry, Waste Thinner Recovery & Cost Saving
JBETT Core Solutions & Core Advantages
Developed by Chongqing JBETT exclusively for spraying workshops, this explosion-proof solvent recycler adopts low-temperature vacuum distillation technology for one-click automatic purification.
High Recovery Rate: 85%-95% recovery efficiency. Recycled solvent reaches industrial standard, reusable for gun cleaning & equipment washing to cut new solvent cost greatly.
Cost & Compliance Saving: Reduce hazardous waste discharge significantly. Payback period only 3-8 months.
Explosion-Proof Structure: Certified explosion-proof design with multiple safety protection against over-temperature, over-pressure & liquid shortage, fully suitable for flammable spraying workshops.
Intelligent Automatic Operation: PLC touch control, automatic feeding, distillation & cooling. Unattended running, easy for new operators.
Corrosion Resistance: 304 stainless steel inner tank, durable for all corrosive spraying mixed solvents.
Product Specifications
| Specification |
Unit |
Value |
| Main unit model |
- |
TE-60 |
| Explosion-proof Grade |
- |
ExdbIIBT3/T4Gb |
| Feed Capacity |
L |
≤60 |
| Maximum Heating Power |
kW |
4.5 kW |
| Power Supply |
V/Hz |
380V (customizable for 50/60Hz) |
| Average Processing Time |
h |
3-3.5 (continuous 24h operation supported) |
| Weight |
kg |
≈175 |
| Overall Dimensions (L×W×H) |
mm |
1160*700*1430 |
| Required Floor Space (L×W×H) |
m |
3.5*3*3 |
| Daily Output (12h) |
L |
60-120L |
| Cooling Method |
- |
Air-cooled / Water-cooled |
| Certifications |
- |
CE/EX |
| Control System |
- |
PLC Control |
| Recovery Efficiency |
(%) |
95 |
Scope Of Application&Application Scenarios
Scope Of Application
This solvent recovery equipment is widely applicable to diversified industrial coating and painting industries, covering auto parts spraying, furniture surface painting, hardware electrostatic spraying, plastic product coating, aluminum veneer architectural spraying and other core scenarios.
It is also suitable for coating production lines in machinery manufacturing, electronic components, daily handicrafts, metal surface treatment and other industries, effectively solving the waste solvent treatment problem in the spraying, painting, coating and cleaning processes of different products.
Recyclable Solvents
The machine is compatible with the recovery and recycling of multiple types of industrial organic solvents, including gun cleaning thinner, xylene, butyl acetate, toluene, ethanol, industrial alcohol, acetone, cyclohexanone and other conventional chemical solvents.
It can stably process all common spraying and coating organic solvents used in industrial production, with strong compatibility, meeting the centralized recovery, purification and cyclic reuse demands of waste solvents in factory mass production.
Hardware spraying, furniture painting, automobile coating and plastic spraying lines consume massive thinners, xylene and gun cleaning solvents every day. Waste solvent accumulation, high hazardous waste disposal cost, rising new solvent procurement price, flammable safety risks and environmental compliance pressure severely squeeze profit margins.
Before JBETEP Solvent Recovery:
This is what unmanaged waste solvent storage looks like at many paint and coating workshops.
- Open barrels of mixed, contaminated solvents and thinners are piled haphazardly across the facility, creating constant fire and explosion risks.
- Volatile vapors from the open containers fill the workspace, exposing workers to toxic fumes and causing unpleasant odors.
- No clear separation of different waste streams leads to cross-contamination, making any potential reuse impossible.
- The growing pile of waste barrels not only clogs valuable production space but also leads to soaring costs for hazardous waste disposal.
- This uncontrolled scenario represents significant safety hazards, environmental non-compliance risks, and a massive drain on operational costs.
After JBETEP Solvent Recovery:
The same facility now operates with a clean, controlled, and fully compliant waste solvent management system.
- A single JBETEP solvent recovery unit replaces dozens of open, hazardous barrels. Flammable waste solvents are safely fed into the explosion-proof system, eliminating open storage risks entirely.
- VOC emissions are drastically reduced. Sealed processing eliminates the toxic fumes and unpleasant odors that once filled the workspace, creating a safer, healthier environment for workers.
- Contaminated solvents are distilled on-site into reusable, high-purity solvent. The client now recycles most of their solvent needs, cutting fresh solvent purchases by up to 95%.
- The once-cluttered floor is now clear. The recovered solvent is stored safely, and waste disposal volumes have been reduced to a fraction of their original size, slashing hazardous waste fees.
- This is the transformation from uncontrolled risk to controlled efficiency—safer, cleaner, and far more profitable.
Whole Machine Explosion-proof Design
Integral explosion-proof design with standard certification, perfectly suitable for flammable & explosive solvent recovery scenarios to eliminate safety hazards.
PLC Operating System
Equipped with integrated PLC intelligent control system, one-click automatic operation. Touch screen visual parameter setting, interlock protection & automatic fault alarm/stop. Simple operation, high precision and greatly reduced manual intervention.
Pressure Controller
Equipped with pressure control device to precisely adjust pressure automatically with overload protection, ensuring stable and safe operation.
The entire machine is made of stainless steel.
The whole machine is made of full stainless steel, corrosion-resistant, acid & alkali proof, easy to clean and durable for long-term industrial use.
Explosion-proof Window
Explosion-proof viewing window allows real-time observation of the internal working conditions of the tank, visual monitoring at all times, safe and convenient inspection.
Working principle
Principle Diagram
Waste Collection → Automatic Feeding → Sealed Distillation → Condensation Purification → Clean Solvent Output → Reuse. Fully sealed design, no volatilization & no odor.
After-sales service & factory guarantee
Direct from the manufacturer, customizable models available. Free installation guidance and remote debugging. Fully compliant with overseas painting plant standards, providing one-stop foreign trade services.
Qualifications
Packaging & Shipping
Packaging:
- Wooden boxes are used for outer packaging;
- Neutral packaging or customized packaging can be provided.
Shipping:
-We can transport goods for you through international express (such as DHL/UPS/TNT, etc.).
You can choose a reasonable transportation method according to your time and budget. In addition,
You can also choose to use your own shipping agent.
| Shipping method |
Note |
| Express |
Door to door, very convenient, don't need to clearance or pick-up |
| By air |
Airport to an airport, you need to do the customs clearance and pick up the goods at your local airport, which you can have a local shipping agent to do for you. |
| By sea |
Port to port and you need to do the customs clearance and pick-up the goods at your local port, which you can have a local shipping agent to do for you. |
Pre-sale Service:
--24 Hours online service for your consultation.
--Help choose right model, and a series of services, people, and advice.
--Give you the best offer.
--Provide discount for many sets order.
--Do customer's request.
--Choose payment term you convenient.
--Promptly production and delivery, inform you in time.
--Can provide invoice value as you like to decrease your tax.
After-sales service:
-- One-year warranty, lifelong technical support.
-- Overseas training for technical engineers can be provided.
-- Remote control technical consultation is provided.
-- Maintenance plan is provided.
